Description

• Can be built on to a continuous line fitted in to a system

• Mid Load holding for use with braided fibre core and cover rope.
• Consistent reliable performance over extended periods
• Low to no maintenance required
• Tough construction with solid aluminium handle
• All Stainless steel metallic parts
• Available with rope range 6-10mm
• Available in multiple units
• Easy installation with 2 bolts
• Can be side mounted to protect an open handle and for a low profile
• Economic price for load rating and durability

Our Part # SPI-XTS0610-1M | Mfr. Part # XTS0610/1M

Technical Information

Rope Range: 6 mm - 10 mm (1/4" - 3/8")
Working Load Limit: 250 kg*
Weight: 0.545 kg (19.1 oz)

*Note: Failure Load is dependent on the rope type/dia being used, typical failure mode will be rope slip or damage.
