Scandvik  |  SKU: SCA99509  |  Manuf. Code: 99509

Scandvik Chargers - Battery Charger Dolphin Pro - 24V - 150 Amp

$4,790.00 USD $6,386.67

Description

The Dolphin Series of battery chargers has always been recognized for its outstanding quality, one that the manufacturer is proud to support with a 2 year warranty. Due to production on a wide scale, Dolphin is able to offer high quality, truly international battery chargers, at a reasonable price.

All Dolphin Battery Chargers and accessories are CE marked and manufactured to UL and ABYC specifications.

Our Part # SCA99509 | Scandvik Part # 99509

Features

Features:

  • LED Display for Programming & Monitoring Functions.
  • Temperature sensor for battery compensation.
  • Switch mode technology and three stage charging design with Power Supply.
  • Modern lightweight and compact design with white aluminum powder coated casing.
  • Universal AC input with automatic voltage switching 115/230 VAC 50/60 Hz (24V-80A, 24V-100A and 24V-150A are 230VAC 50/60 Hz ONLY).
  • 4 screw simple install with easy access removable panel.
  • ISO 9002 certified manufacturing plant.

Technical Information


DescriptionImperialMetric
Input Voltage230V (+/-15%)
Frequency50/60 hz (+/-10%)
Cos> 0.90 typ
Efficiency0.85
Mounting6 x #8 Screws
Width14.00 in.355.00 mm.
Height16.00 in.405.00 mm.
Depth9 1/2 in.241.00 mm.
Weight42.00 lb.19.00 kg.
