Scandvik Chargers - Battery Charger Dolphin Pro - 24V - 150 Amp
Scandvik Chargers - Battery Charger Dolphin Pro - 24V - 150 Amp is backordered and will ship as soon as it is back in stock.
Description
Description
The Dolphin Series of battery chargers has always been recognized for its outstanding quality, one that the manufacturer is proud to support with a 2 year warranty. Due to production on a wide scale, Dolphin is able to offer high quality, truly international battery chargers, at a reasonable price.
All Dolphin Battery Chargers and accessories are CE marked and manufactured to UL and ABYC specifications.
Our Part # SCA99509 | Scandvik Part # 99509
Features
Features
Features:
- LED Display for Programming & Monitoring Functions.
- Temperature sensor for battery compensation.
- Switch mode technology and three stage charging design with Power Supply.
- Modern lightweight and compact design with white aluminum powder coated casing.
- Universal AC input with automatic voltage switching 115/230 VAC 50/60 Hz (24V-80A, 24V-100A and 24V-150A are 230VAC 50/60 Hz ONLY).
- 4 screw simple install with easy access removable panel.
- ISO 9002 certified manufacturing plant.
Technical Information
Technical Information
Description | Imperial | Metric |
---|---|---|
Input Voltage | 230V (+/-15%) | |
Frequency | 50/60 hz (+/-10%) | |
Cos | > 0.90 typ | |
Efficiency | 0.85 | |
Mounting | 6 x #8 Screws | |
Width | 14.00 in. | 355.00 mm. |
Height | 16.00 in. | 405.00 mm. |
Depth | 9 1/2 in. | 241.00 mm. |
Weight | 42.00 lb. | 19.00 kg. |
