Quick Windlass - Tumbler TB4 1000W Vertical Electric 12V Drum Only

$2,520.00 USD $2,964.71

Description

The Quick TB4 Tumbler horizonal capstan winch is suitable for boats from 16m to 22m (52 to 72ft). The capstan features a AISI 316 stainless steel base and drum (INOX steel) with an anodised aluminium gearbox and an IP67 watertight motor, making it well protected and durable. Supplied with a nylon handle control, anchoring has never been easier. The Quick capstan winch features a 142mm (5" - 19/32) diameter drum which is suitable for rope. This unit comes equipped with an IP67 watertight motor.

Features

Features:

  • Warping Winches
  • AISI Stainless steel 316 base and drum
  • IP67 Motor watertight
  • Anodized aluminium gearbox

Knowledge Base

Technical Information


DescriptionImperialMetric
Unit MaterialAISI 316L
Motor TypeCapstan
Drum / No DrumNo drum
Power Supply12 V.
Power (W)1000 W.
Boats up to46.00 - 59.00 ft.14.02 - 17.98 m.
Chain FallRight hand
