Jabsco 4" (101.6 mm) Heavy Duty Flangemount Blower, 250 CFM - 12V - White
Jabsco 4" (101.6 mm) Heavy Duty Flangemount Blower, 250 CFM - 12V - White is backordered and will ship as soon as it is back in stock.
Description
Description
Heavy Duty Flangemount Blower
Heavy Duty Blowers are designed for applications such as commerical or high use engine room ventilation and extraction where a long life requirement demands heavy duty motors with long brush life. Built to provide the same high outputs as our standard specification blowers.
Our Part # JAB-35760-0092 | Jabsco Part # 35760-0092
Features
Features
Features:
- 5,000 hr motor life for the heaviest of applications.
- Continuous duty.
- Efficient high volume air flow.
- Outlet flange mounts directly on bulkhead.
- Slip on inlet ducting connection.
- Low current draw.
- Corrosion resistant materials throughout.
- Dimensionally stable quiet running Delrin rotors.
- Complies with USCG 183.410 and ISO 8846 MARINE (Ignition Protection)
- ISO 9097 MARINE (Electric Fans)
Technical Information
Technical Information
Description | Imperial | Metric |
---|---|---|
Output volume | 250.00 cfm. | 7.10 m³/min. |
Volts | 12V DC | |
Fuse Size | 15 | |
Height | 9.00 in. | 23.00 cm. |
Width | 8 3/4 in. | 22.00 cm. |
Length | 9 1/2 in. | 24.00 cm. |
Fitting | 4.00 in. ducting | 100.00 mm. ducting |
Weight | 6.00 lb. | 2.70 kg. |
