Harken Rigid Boom Vang - Vang Master 1 - Boat Size: 18 ft (5.5 m) to 26 ft (7.9 m)

Standard Vang-Master rigid vangs are available for boats with vang fittings on the boom and mastbase. Typical boat lengths: 13.7 - 17.1 m (45'- 56').

Purchase separately:

• Vang gooseneck and boom lug fittings if required.
• 4:1 or 6:1 block and line kit - Cascades the 2:1 purchase to 8:1 or 12:1 respectively Cascades the 4:1 purchase to 16:1 or 24:1 respectively.
• Cleats and accessories for double-ended systems.

Our Part # HARVM13240 | Harken Part # VM13240

Pin center length (closed): 813 mm
Pin center length open: 1016 mm
Stroke: 203 mm
Weight: 1.25 kg
Pin Ø: 10 mm
Jaw width: 6 mm
Maximum return pressure: 159 kg
Boat length: 5.5 - 7.9 m
