Purchase systems are the unsung heroes of sailing, simplifying complex maneuvers and making sail control effortless. By combining blocks and ropes, these systems multiply your effort, allowing you to handle heavy loads with ease. In this guide, we’ll explore simple and compound purchase systems, explain how to calculate mechanical advantage, and offer tips for designing your own.
Simple Purchase Systems
Starting with the basics, a simple purchase system uses one block and one line. This 1:1 ratio means the force applied matches the load. It’s ideal for straightforward tasks like adjusting sail tension or raising a centerboard. For instance, pulling 10cm of line in a 1:1 system moves the load 10cm, offering direct and efficient control.
This setup is common in systems like spinnaker or jib sheets on dinghies and small keelboats, where simplicity and reliability are key.
Understanding Mechanical Advantage
Mechanical advantage (MA) is your boat’s secret weapon. It allows you to manage higher loads with the same effort. By increasing the number of blocks in a system, you can amplify the MA to ratios like 2:1, 4:1, or even 6:1, depending on your needs. For example:
- A 2:1 system reduces the effort needed to move a load by half, but doubles the amount of line you must pull.
- Highly advanced setups, like the 54:1 system on an International Moth, make handling extreme loads possible.
However, increasing MA can reduce the tactile feedback sailors rely on, making it important to balance efficiency with "feel."
Compound Purchase Systems
Compound systems take MA to the next level by combining multiple simple systems. These setups are perfect for heavy-duty tasks like mainsheet systems on racing yachts. They provide coarse and fine adjustments, offering superior control and making it easier to handle large loads.
For instance, a coarse 4:1 system can quickly bring the mainsail into position, while a fine-tune 12:1 system ensures precise adjustments for optimal performance.
How to Calculate and Design a Purchase System
Designing a purchase system involves several key steps:
- Identify the purpose: Define the task, such as hoisting sails or controlling rigging.
- Assess load requirements: Calculate the maximum load the system will handle, adding a safety margin.
-
Calculate the MA: Divide the load by the effort you’re willing to apply to determine the necessary ratio.
- Choose components: Select blocks and lines based on the calculated MA and space constraints.
- Test and maintain: Install the system, test under load, and establish a maintenance routine to ensure long-term reliability.
By following these steps, you can create a custom purchase system tailored to your needs, improving efficiency and safety.
Examples of Purchase Systems
From mainsheets and travelers to vangs and cunninghams, purchase systems play a vital role in boat operations. Without blocks and cleats, these systems simply wouldn’t function. By understanding the principles of MA, you can optimize your boat’s setup and make sailing more efficient and enjoyable.
